product introduction

The three-in-one filling machine is suitable for filling various mineral water, purified water, drinking water, etc. It adopts the neck clamping transmission technology to achieve fully automatic bottle rinsing, filling, capping and other processes. The three-in-one filling equipment is one of the main devices produced by small and medium-sized water manufacturers. It is developed based on advanced foreign technology and in accordance with the filling process requirements of pure water.

 product details

                                               Rinsing section

                             1.After entering the main unit, the bottles are conveyed into the                                  bottle rinsing machine through the transmission star wheel


                           2.The bottle clamp holds the bottle mouth and flips it up 180° along the                             bottle-rinsing guide rail to make the bottle mouth face down


                           3.  The nozzle of the bottle rinsing clamp sprays sterile water to                                              rinse the   inner walls of the bottles


                                              Filling section

                    During filling, the bottles are lifted by cylinders, and the high-speed operation is stable and reliable.

                   Compressed air is connected to the lifting cylinder through the air intake distributor，

                    When in operation, compressed air is injected into the cylinder through the                    injection pipe

                                     Screw cap section

                     The bottles enter the capping machine through the transmission star                                wheel,  and the anti-rotation knife on the capping machine gets stuck at the                      neck part，

                     Together with the outer neck guard plate of the capping machine, keep                            the  bottle upright and prevent it from rotating.
