product introduction

The carbonated beverage production line belongs to one of the isobaric filling production line equipment. The carbonated beverage filling machine maintains a certain filling pressure in the storage tank. When the container to be filled enters the filling machine, it is first filled with gas. The gas can be compressed air or carbon dioxide gas, with carbon dioxide gas being preferred. When the pressure inside the container is the same as that in the storage tank, the liquid will be filled through the open filling valve along with its own weight. During the filling process, the gas inside the container should be smoothly discharged and returned to the storage tank or gas chamber.

 product details

                                             Flushing part

                         1.After entering the main unit, the bottles are conveyed into the bottle                              rinsing machine through the transmission star wheel


                         2.The bottle clamp holds the bottle mouth and flips it up 180° along the                             bottle-rinsing guide rail to make the bottle mouth face down.


                          3.The nozzle of the bottle rinsing clamp sprays sterile water to rinse the                                inner walls of the bottles.

                                              Filling section

 1.The filling volume can be fine-tuned and the liquid level remains the same                   after filling

 2.All 304/316 stainless steel contact parts and liquid tanks are finely polished with no dead corners and are easy to clean

3.During filling, the bottles are lifted by cylinders, and the high-speed operation is stable and reliable.

                                     Capping part

                      1.When the capping head takes out the cap through the cap distribution                                 tray, the top cap sleeve holds the cap and straightens the cap.

                     2.To ensure the correct position of the lid in the capping die and guarantee                          the capping quality.
