product introduction

The carbonated beverage production line belongs to one of the isobaric filling production line equipment. The carbonated beverage filling machine maintains a certain filling pressure in the storage tank. When the container to be filled enters the filling machine, it is first filled with gas. The gas can be compressed air or carbon dioxide gas, with carbon dioxide gas being preferred. When the pressure inside the container is the same as that in the storage tank, the liquid will be filled through the open filling valve along with its own weight. During the filling process, the gas inside the container should be smoothly discharged and returned to the storage tank or gas chamber.

 product details

                                             Flushing part

                         1.The air conveying device directly connected to the bottle                                                     dial enters the bottle passage


                            2.304/316 stainless steel gripper with plastic pad to ensure                                             minimal bottle collision during the cleaning process.


                          3.304/316 stainless steel cleaning pump, making the machine more                                  durable.

                                              Filling section

1.304/316 stainless steel high-precision filling nozzles


2.The filling volume can be fine-tuned and the liquid level remains the same                        after filling


3.All 304/316 stainless steel contact parts and liquid tanks are finely                               polished with no dead corners and are easy to clean

                                     Capping part

                      When the capping head takes out the cap through the cap distribution                                 tray,the top cap sleeve holds the cap and straightens the cap.

                     To ensure the correct position of the lid in the capping die and guarantee                               the capping quality.
